1) Turn the holding nuts clockwise (looking down) to lower the height-adjustment feet and
secure the pump.
2) Adjust the height of the feet evenly to ensure that the pump base is level.
3) The difference in height between the two sides of the pump base shall not exceed 1mm.
The adjustment allowance is approximately 15 mm.
3.1.3 Pump Anchoring (Option)
Pumps include casters for short distance moves and foot adjusters to set height and stop pump from
rolling as described in Section 3.1.2. However, an earthquake may cause the pump to move or fall. To
secure the pump, EBARA provides [optional] anchor brackets for Model EV-SA20 dry pump to fasten the
pump body to the floor. Anchor the pump to the floor or other firm surface with these brackets.
For bracket dimensions and locations, see the accompanying drawings.
Select anchor bolts that are appropriate for the weight of the pump and the anchoring surface; install
them per the manufacturer’s recommendations.
CAUTION
Do not step on the pump or place objects upon it.
CAUTION
The neck portion of the casters will vibrate when the caster is moving.
Keep fingers and feet away.
CAUTION
If the pump is not leveled, shortage of the lubrication oil supply to the bearing may be
caused.
NOTE
Floor vibrations and airborne noise will increase unless the adjustment feet are used.
CAUTION
When using the tool to adjust the height of the adjustment feet, be careful of handling
of the tool.
