P.42
PM10U
EBARA
CORPORATION
5.2 START / STOP
The control mode can be set Local/Remote at any time by LO/RE button. (See Fig. 5.1)
After stopping the pump, set in accordance with the operating conditions.
a) START
【LOCAL MODE】
Push and select “LOCAL MODE”.
After checking that the LO/RE lamp is ON, push .
The pump will start and the RUN lamp will be ON.
【REMOTE MODE】
Push , select “REMOTE MODE” .
After checking that the LO/RE lamp is OFF, input RUN signal from the control connector.
(See table 3.1)
The pump will start and the RUN lamp will be ON.
[NOTE] All buttons are located on the operation panel.
[NOTE] The pump will not start when an ALARM has been generated.
[NOTE] The control mode can not be selected during RUN lamp is ON.
WARNING
The pump starts immediately after the inverter on-delay time if the CP turns on with
remote RUN signal in Remote mode. Make sure the piping are connected properly.
Execute the safety preparations against sudden start the pump.
CAUTION
If the pump does not start smoothly, the exhaust gas may be back-streaming from the
outlet port. Please check the system condition and retry the start process.
Push
LOCAL
MODE
REMOTE
MODE
Fig. 5.1 Switching Between LOCAL and REMOTE
NOTE
Do not exhaust the process gases until at least 30 minutes after the pump has been
started. The pump casing temperature will stabilize after about 2 hours and it is
recommended not to start exhausting the process gases earlier than this.
To Next Page
