3.4.1.2.2. Single Location Transmitters with the /H Humidity Option
3.4.1.2.3 Dual Location Transmitters without the /H Humidity Option
View is active when LCD NAME or LCD SERV = ON
< N A M E >
Not visible when LCD NAME = OFF
< S E R V >
Not visible when LCD SERV = OFF
View is always active when RHCONFIG=RH
# # # # # C F M # # . # F
Auto space.
# # # % R H
HCONFIG = RH
View is always active when RHCONFIG=DPT
# # # # # C F M # # . # F
Auto space.
# # # F D P T # # # % R H
HCONFIG = DPT
View is always active when RHCONFIG=ENTH
# # # # # C F M # # . # F
Auto space.
# # # B t u / l b # # # % R H
HCONFIG = ENTH
Alarm View: View is active when LOW or HIGH Airflow Alarm = Active
A L A R M : L O W F L O W
Not visible when low flow alarm is inactive.
A L A R M : H I G H F L O W
Not visible when high flow alarm is inactive.
View is active when TRBL = Active and LCD TRBL = ON
# # [ E R R O R D E S C R ]
# # [ E R R O R D E S C R ]
## = Second Trouble Code, if applicable.
Toggle through additional errors.
View is active when LCD NAME = ON (Default = OFF)
< N A M E >
View is always active
< S E R V 1 >
Not visible when LCD SERV = OFF.
# # # # # C F M # # . # F
Auto space.
View is active when LOW or HIGH Airflow Alarm = Active
A L A R M : L O W F L O W
Not visible when low flow alarm is inactive.
A L A R M : H I G H F L O W
Not visible when high flow alarm is inactive.
Note: There is no fan alarm available on dual location units
View is always active
< S E R V 2 >
Not visible when LCD SERV = OFF.
# # # # # C F M # # . # F
Auto space.
Note: There is no airflow alarm for location 2
Note: There is no fan alarm available on dual location units
View is active when TRBL = Active and LCD TRBL = ON
# # [ E R R O R D E S C R ]
# # [ E R R O R D E S C R ]
## = Second Trouble Code, if applicable.
Toggle through additional errors.
