3-O&M_Settings_r1r Section 3Page 15
EBTRON, Inc • 1663 Hwy 701 S., Loris, SC 29569 • Toll Free: 800-2EBTRON (232-8766) • Fax: 843-756-1828 • EBTRON.com
3.4.1.2.4. Dual Location Transmitters with the /H Humidity Option
This configuration is not available.
3.4.2. LCD Display Mode [LCD DSPL]
Enables or disables LCD option during normal operation.
[Menu path: SETTINGS >↓ DISPLAY >↓ LCD DSPL]
Default: ON (normal display operation)
Optional Settings: OFF (displays EBTRON {transmitter model} only)
3.4.3. LCD Location Name Indication [LCD NAME]
Show or hide the location name, NAME, on the LCD.
[Menu path: SETTINGS >↓ DISPLAY >↓ LCD NAME]
Default: OFF (do not display the location name)
Optional Settings: ON (display the location name)
3.4.4. LCD Service Description Indication [LCD SERV]
Show or hide the service description, SERV, on the LCD.
[Menu path: SETTINGS >↓ DISPLAY >↓ LCD SERV]
3.4.4.1. SINGLE LOCATION ALL PROBE TYPES
Default: OFF (do not display the service location)
Optional Settings: ON (display the service location)
3.4.4.2. DUAL LOCATION ALL PROBE TYPES
Default: ON (display the service location)
Optional Settings: None.
3.4.5. LCD System Trouble Indication [LCD TRBL]
Show or hide active trouble codes and faults on the LCD.
[Menu path: SETTINGS >↓ DISPLAY >↓ LCD TRBL]
Default: ON (display faults and trouble codes)
Optional Settings: OFF (do not display faults and trouble codes)
3.4.6. LCD Airflow Units of Measure [LCD UM]
The airflow units of measure displayed on the LCD.
[Menu path: SETTINGS >↓ DISPLAY >↓ LCD UM]
Default and Optional Settings: See appropriate probe type.
The area parameter(s) [AREA] of -F, -U and -B probe types must be entered (i.e. not equal to the
factory default value of {null}) for the LCD UM=CFM [L/s] option to be available. “ENTER AREA
<OK>” will be displayed when CFM [L/s] is selected. Press ENT or ESC to return to the “*LCD
UM=FPM [m/s]” menu prompt.
