3-O&M_Settings_r1r Section 3Page 24
EBTRON, Inc • 1663 Hwy 701 S., Loris, SC 29569 • Toll Free: 800-2EBTRON (232-8766) • Fax: 843-756-1828 • EBTRON.com
3.5.13.3. -F PROBE TYPE
3.5.13.3.1. AO2 UM = FPM [m/s]
Default: 10000 (FPM) [50.0 (m/s)]
Optional Settings: 100 to 15000 (FPM) [0.5 to 75.0 (m/s)]
3.5.13.3.2. AO2 UM = CFM [L/s]
Default: {10000 x AREA} (CFM) [{50000 x AREA} (L/s)]
Optional Settings: 5 to 999999 (CFM) [5 to 999999 (L/s)]
3.5.13.4. ALL PROBE TYPES
Some B.A.S. application controllers use “span” rather than minimum- and full-scales. The span is
equal to the full-scale – minimum scale and the offset is equal to the minimum scale.
EBTRON airflow measurement accuracy is percent of reading. Decreasing the full scale does not
improve measurement accuracy. Today’s application controllers generally have sufficient accuracy
and input resolution to use the default output scaling of the transmitters.
Note: Sections 3.5.14. only applies when AO2 ASGN=ALRM or TRBL.
3.5.14. AO2 Output on an Inactive Notification Alarm [NO FAULT]
The output of AO2 when the notification alarm status is inactive.
[Menu path: SETTINGS >↓ ANALOG OUT >↓ NO FAULT]
Default: HI (output is set to 100%)
Optional Settings: LO (output is set to 0%)
Note: Sections 3.5.15. to 3.5.18. only apply to Advantage IV GTx116e remote transmitters that have the
humidity sensor option, /H, provided with the -P sensor probe type.
3.5.15. AO3 Assignment [AO3 ASGN]
The object assigned to analog output AO3.
[Menu path: SETTINGS >↓ ANALOG OUT >↓ AO3 ASGN]
Default: The current parameter setting for H CONFIG
Optional Settings: None
3.5.16. AO3 Unit of Measure [AO3 UM]
The unit of measure of AO3.
[Menu path: SETTINGS >↓ ANALOG OUT >↓ AO3 UM]
The unit of measure is dependent on the RH sensor configuration.
3.5.16.1. H CONFIG=RH
Default: % RH
Optional Settings: None
