Ebtron Advantage IV Series User Manual

4-O&M_Tools_r1g Section 4Page 4
EBTRON, Inc • 1663 Hwy 701 S., Loris, SC 29569 • Toll Free: 800-2EBTRON (232-8766) • Fax: 843-756-1828 • EBTRON.com
FAN WIZ (located in the TOOLS menu)
Use ↑↓ buttons to modify, {ENT} to accept and move to next prompt, {ESC} to move to previous prompt.
If the LOCK is enabled, pressing enter will indicate "CONFIG LOCKED" and this tool will not be available.
Navigate entire menu to step 14 to save settings. Press {ESC} at any time to exit without saving changes.
STEP
PROMPT RESPONSE DESCRIPTION
SKIP TO
1
CONFIG?
SWSI↓
Single inlet.
DWDI↑↓
Dual inlet.
ARRAY↑
Fan array.
4
2
LOCATION?
1↓
Location 1 of 2.
2↑
Location 2 of 2.
Note: This prompt will only be visible on 2 location devices. Single location devices start at prompt #3.
3
DIAM?
{null}↑
The free area duct or opening diameter, in inches [mm]. Value cannot be {null}.
14
Note: The diameter should be determined at the upstream leading edge where sensor node is installed.
The AREA of DWDI fans will be doubled. Dual location devices will indicate DIAM1 or DIAM2 in lieu of
DIAM.
4
FANS?
2↑↓
Number of fans in the array, 2 to 8.
5
DISTR?
EQUAL↓
The number of sensors, 1 or 2, is the same for all fans in the array.
VAR↑
The number of sensors, 1 or 2, is not the same for all fans in the array.
6
SENS/FAN?
1↓
1 sensor node per fan.
2↑
2 sensor nodes per fan.
Note: If DISTR is set to VAR, there will be a separate prompt for each fan and the SENS/FAN prompt will
be followed with the fan number (i.e. SENS/FAN1 … SENS/FANn)
7
AREA/FAN?
EQUAL↓
The area is equal for each fan in the array.
VAR↑ The area is different for at least one fan in the array..
8
METHOD?
CALC↓
The area is calculated based on dimensions provided by user.
AREA↑
The area is directly entered by the user.
13
9
TYPE?
INLET↓
Probes are mounted in the fan inlet cone
DMPR↑
Probes are mounted in a backdraft damper
11
10
DIAM?
{null}↑
The free area duct or opening diameter, in inches [mm]. Value cannot be {null}.
14
Note: The diameter should be determined at the upstream leading edge where sensor node is installed.
If AREA/FAN is set to VAR, there will be a separate prompt for each fan and the DIAM prompt will be
followed with the fan number (i.e. DIAM1 … DIAMn).
11
WIDTH?
{null}↑
The inside damper width, in inches [mm]. Value cannot be {null}.
If AREA/FAN is set to VAR, there will be a separate prompt for each fan and the WIDTH prompt will be
followed with the fan number (i.e. WIDTH1 … WIDTHn).
12
HEIGHT?
{null}↑
The inside damper height, in inches [mm]. Value cannot be {null}.
14
If AREA/FAN is set to VAR, there will be a separate prompt for each fan and the HEIGHT prompt will be
followed with the fan number (i.e. HEIGHT1 … HEIGHTn).
13
AREA?
{null}↑
The area of the fan inlet, in sq ft [sq m] where the sensor node is installed. Value cannot be {null}
Note: The area should be determined at the upstream leading edge where sensor node is installed.
Enter the area of one inlet on DWDI fans or a single fan in an array if AREA/FAN is set to EQUAL. If
AREA/FAN is set to VAR, there will be a separate prompt for each fan and the AREA prompt will be
followed with the fan number (i.e. AREA1…AREAn).
14
SAVE?
YES↓
Save changes and return to normal operation.
NO↑
Do not save changes and return to normal operation.
