Chengdu Ebyte Electronic Technology Co.,Ltd E180-Z6907A User Manual
Copyright ©2012–2019,Chengdu Ebyte Electronic Technology Co., Ltd.
4-17
The reconnection period
of the parent node lost
the network
29
Send
:
FE 01 29 FF
Return
:
FB 29 net_rejoinperiod
Send
:
FE 01 29 FF
Return
:
FB 29 05
The maximum number
of times the parent node
lost network
reconnection
30
Send: FE 01 30 FF
Return: FB 30 net_rejoincount
Send: FE 01 30 FF
Return: FB 30 05
Read wireless
configuration ID
31
Send: FE 02 31 FF
Return: FB 31 header
Send: FE 02 31 FF
Return: FB 31 A8 8A
Read all device data
FE
Send: FE 2F FE FF
Return: FB FE all_info
Send:FE 2F FE FF
Return:FB FE 03 02 FE 5B
F6 FA 1F 1C 21 FE FF 57
B4 14 00 00 0C 46 0C FE
FF 9F FD 90 01 0B 0A 09
54 00 00 00 0A 1C 21 FE FF
57 B4 14 02 00 FF 05 05 A8
8A
Read remote/local
GPIO level
20
Command: FE 03 20 GpioId FF
Return: FB 20 GpioId In/Out level
Send: FE 03 20 00 FF
Return: FB 20 00 01 01
Read remote/local
PWM parameter
21
Command
:
FE 06 21 PWMId FF
Return
:
FB 21 PWMId start/stop
Period Period duty duty
Send
:
FE 06 21 00 FF
Return
:
FB 21 00 01
0A 3E 63 50
Read local /remote
ADC state
22
Command
:
FE 03 22 adcid FF
Return
:
FB 22 adcid voltage1
voltage2
Send
:
FE 03 22 00 FF
Return
:
FB 22 00 0C E4
Read end-device node
numbers of the parent
node
32
Command: FE 01 32 FF
Return: FB 32 child_count
Send: FE 01 32 FF
Return: FB 32 0A
Read end-device node
schedule of the parent
node
33
Command:FE 0E 33 FF
Return: FB 33 index dev_type
Short_Addr Mac_Addr
Send: FE 0E 33 FF
Return: FB 33 00 03 FE 5B
0A 1C 21 FE FF 57 B4 14
Read the firmware
version number
34
Command: FE 03 34 FF
Return:FB 34 FirmwareVersion
Send: FE 03 34 FF
Return: FB 34 82 69 01
Read the delayed printing time of
AUX wake up external MCU
serial port in wireless receiving
state
35
Send
:
FE 01 35 FF
Return
:
FB 35 AUX_delaytime
Send
:
FE 01 35 FF
Return
:
FB 35 04
Read UART wake up keep time
36
Send
:
FE 01 36 FF
Return
:
FB 36 Uart_holdtime
Send
:
FE 01 36 FF
Return
:
FB 36 64
Read port info.
37
Send: FE 05 37 FF
Return: FB 37 Endpoint_info
Send: FE 05 37 FF
Return: FB 37 01 FE B0
05 04
