Chengdu Ebyte Electronic Technology Co.,Ltd E180-Z6907A User Manual
Copyright ©2012–2019,Chengdu Ebyte Electronic Technology Co., Ltd.
4-21
0x02 Joined the network
6.6.5 Network PAN_ID
pan_id:
0x0000~0xFFFE fixed network PAN_ID
0xFFFF stochastic network PAN_ID
PANID Parameters need to be configured before setting up or joining the network
6.6.6 Network short address
Short_Addr:2 Byte Address randomly assigned by coordinator
6.6.7 MAC address
Mac_Addr: 8 Byte
6.6.8 Short address of parent node
Coor_shortAddr:2 Byte Short address of the parent node of the current node, if it is coordinator, it should be
0x0000
6.6.9 Parent node MAC address
Coor_Mac_Addr:8 Byte The parent node's long address of the current node
6.6.10 Network group number
group:Group number range 0x01~0xFF(Default 1)
6.6.11 Network channel
Channel:Channel range 0x0B(11)~0x1A(26)(default 11 channels)
Channel The parameters need to be configured before entering the network or establishing a network.
6.6.12 Transmit power
txpower:Transmit power level(default 7dBm)
Adjustable range -37dbm,-30dbm ,-27.5dbm,-23.3dbm,-18.8dbm,-13.6dbm,-9.5dbm,-4.3dbm,-0.6dbm,5dbm,7dbm
txpower
Transmit
power level
Buad
Baud rate
