Ebyte E180-Z6907A User Manual

Chengdu Ebyte Electronic Technology Co.,Ltd E180-Z6907A User Manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co., Ltd.
5
1.4 Application
 Smart home and industrial sensors；
 Security system and positioning system;
 Wireless remote control, UAV;
 Wireless game remote control;
 Health care products；
 Wireless voice, wireless headphones；
 Meter reading architecture (AMI);
 Automotive industry applications;
 Building automation solutions;
 Automation application of agricultural greenhouse.
2. Technical parameter
2.1 Limit parameter
Main parameter
Performance
Remark
Min
Max
Voltage supply（V）
1.9
3.6
Voltage over 3.6V will cause permanent damage to module
Blocking power
（
dBm
）
-
10
Chances of burn is slim when modules are used in short
distance
Working temperature
（℃）
-40
+85
Industrial grade
2.2 Operating parameter
Main parameter
Performance
Remark
Min.
Typ.
Max.
Operating voltage（V）
1.9
3.3
3.6
≥3.3 V ensures output power
Communication level（V）
3.3
For 5V TTL, it may be at risk of burning down
Working temperature（℃）
-40
-
+85
Industrial design
Frequency
（
MHz
）
2405
-
2480
Support ISM band
Po
we
r
co
TX current
（
mA
）
40
Instant power consumption
RX current（mA）
35
Sleep current（μA）
16.5
Software shutdown
