Chengdu Ebyte Electronic Technology Co.,Ltd E180-Z6907A User Manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co., Ltd.
4-25
6.6.23 Read all network parameters
all_info：FB FE 03 02 FE 5B F6 FA 1F 1C 21 FE FF 57 B4 14 00 00 0C 46 0C FE FF 9F FD 90 01 0B 0A 09 54 00
00 00 0A 1C 21 FE FF 57 B4 14 02 00 FF 05 05 A8 8A
Node type 03； Network status 02； Network short address FE 5B; Local network short address F6 FA；
Local MAC address 1F 1C 21 FE FF 57 B4 14；Parent node network short address 00 00； Parent node MAC address
0C 46 0C FE FF 9F FD 90； Network group 01；Channel 0B；Transmitting power 0A；Baud rate 09；sleep time 54；
Target network short address 00 00； Target network group 00；Target long address 0A 1C 21 FE FF 57 B4 14；
System transmitting mode 02； Data output mode 00； Network open time FF( coordinator is valid and this module
does not support)；rejoin period 05； rejoin times 05；Wireless ID A8 8A；
6.6.24 Configure the delayed printing time of AUX wake up external MCU serial port in wireless
receiving state
AUX_delaytime: 1～255 unit is ms, the default parameter is 4ms, that is, after the module receives wireless data, first
pull down the AUX pin to wake up the external MCU, and then delay 4ms to output the serial port data to the external
MCU.
6.6.25 Configure serial port wake-up hold time
Uart_holdtime: The unit of 1～255 is 10ms, the default parameter is 100, that is, the serial port will keep waking up for
100*10ms after waking up, and then going to sleep after 1000ms.
6.6.26 Configure endpoint information
Endpoint_info：data format of 5 bytes are endpoint clusterId_H clusterId_L profileId_H profileId_L
Default is endpoint 0x01, clusterId 0xfeb0, profileId 0x0504
6.6.27 Set Link key of trust center
TrustCentLinkKey：data length of 16 bytes, default key of ZigBee alliance is
0x5A 0x69 0x67 0x42 0x65 0x65 0x41 0x6C
0x6C 0x69 0x61 0x6E 0x63 0x65 0x30 0x39
Take effect once restart
