Chengdu Ebyte Electronic Technology Co.,Ltd E180-Z6907A User Manual
Copyright ©2012–2019,Chengdu Ebyte Electronic Technology Co., Ltd.
4-18
Read link key of trust center
38
Send
:
FE 10 38 FF
Return
:
FB 10 TrustCentLinkKey
Send
:
FE 10 38 FF
Return
:
FB 38
5A 69 67 42 65 65 41 6C
6C 69 61 6E 63 65 30 39
6.5.3 Configuration instruction set
Configure device type
Send
:
FD 01 01 dev_type FF
Return
:
FA 01
Send
:
FD 01 01 03 FF
Return
:
FA 01
Configure PAN_ID
Send:FD 02 03 pan_id FF
Return:FA 03
Send:FD 02 03 FE 5B FF
Return:FA 03
Configure the network group
number
Send:FD 01 09 group FF
Return:FA 09
Send:FD 01 09 01 FF
Return:FA 09
Configure communication channel
Send:FD 01 0A channel FF
Return:FA 0A
Send:FD 01 0A 0B FF
Return:FA 0A
Configure transmit power (0-10
corresponding power)
Send:FD 01 0B txpower FF
Return:FA 0B
Send:FD 01 0B 0A FF
Return:FA 0B
Configure serial port baud rate
Send
:
FD 01 0C baud FF
Return
:
FA 0C
Send
:
FD 01 0C 09 FF
Return
:
FA 0C
Configure sleep time (end-device
valid)
Send
:
FD 01 0D sleep_time FF
Return
:
FA 0D
Send
:
FD 01 0D 54 FF
Return
:
FA 0D
Configure the target network short
address
Send:FD 02 23 dec_addr FF
Return:FA 23
Send:FD 02 23 00 00 FF
Return:FA 23
Configure the target network
group number
Send:FD 01 24 netid FF
Return:FA 24
Send:FD 01 24 00 FF
Return:FA 24
Configure target long address
Send:FD 08 25 dec_mac FF
Return:FA 25
Send:FD 08 25 0A 1C 21
FE FF 57 B4 14 FF
Return:FA 25
Configure system sending mode
Send:FD 01 26 mode FF
Return:FA 26
Send:FD 01 26 02 FF
Return:FA 26
Configure the data output mode of
the module
Send
:
FD 01 27 mode FF
Return
:
FA 27
Send
:
FD 01 27 00 FF
Return
:
FA 26
Configure to open centralized
network time(Coordinator is valid,
this module does not support it)
Send
:
FD 01 28 time FF
Return
:
FA 28
Send
:
FD 01 28 FF FF
Return
:
FA 28
Configure the period of rejoin
after the end-device node loses the
parent node.
Send:FD 01 29 time FF
Return:FA 29
Send:FD 01 29 05 FF
Return:FA 29
The maximum rejoins times
after the end-device node loses the
parent node
Send:FD 01 30 time FF
Return:FA 30
Send:FD 01 30 05 FF
Return:FA 30
Configure the wireless remote
Send:FD 02 31 header FF
Send:FD 02 31 A8 8A FF
