Chengdu Ebyte Electronic Technology Co.,Ltd E180-Z6907A User Manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co., Ltd.
4-24
period: pwm period time (unit 1 = 1ms)
Recommended setting range: 0x02 ～ 0x1f4
Period1 High 8 bits of period
Period2 Low 8 bits of period
duty: pwm duty cycle time (unit 1 = 1ms)
Can be set from 0x01 to 0x1f3
duty1 High 8 bits of the duty cycle
duty2 Low 8 bits of the duty cycle
Note: The period value must be greater than duty cycle duty, and the difference between the recommended period
and the duty cycle duty is greater than 2ms. If the period is less than the duty cycle, the system default cycle period is
equal to twice the duty cycle duty, and the duty cycle here represents the high level time.
6.6.21 User adc parameter
Adc Peripheral read data format（3 Byte）：adcid voltage1 voltage2
adcid：ADC channel ID
VDD Power supply voltage detection
Voltage：Read ADC channel voltage value（ Unit: mV）
Detectable range 0x0000～0x0E74 （0～3700）
voltage 1 Indicates high 8 digits
voltage 2 Indicates low 8 bits
For example, Read value：voltage =0x0C voltage =0xE4
Then voltage value is：voltage =0x0CE4
Note: If the power supply voltage is the highest 3.3V, the detection range of the ADC can reach 3.3V.
6.6.22 Configure all network parameters
all_info：FD 1A FE 03 FE 5B 01 0B 0A 09 54 00 00 00 0A 1C 21 FE FF 57 B4 14 02 00 FF 05 05 A8 8A FF
Node type 03；Network short address FE 5B； Network group number 01； Channel 0B；Transmitting power
0A；Baud rate 09； Sleep time 54； Target network short address 00 00；Target network group number 00； Target
long address 0A 1C 21 FE FF 57 B4 14；System transmitting mode 02； Data output mode 00 ；Network open time
FF( coordinator is valid and this module does not support) ；rejoin period 05；rejoin times 05；Wireless ID A8 8A；
