Echo shindaiwa CS-501SX - Service Hint for Heated Handle (CS-501 SXH Only)

REAR HANDLE AND CONTROL SYSTEM
CS-501SX, CS-501SXH
501sx
63
9-3 Service hint for heated handle (CS-501SXH only)
( A ) Front handle assembly (with heater)
( B ) Band
( C ) Handle cover
( D ) Heater switch
( E ) Nut
( F ) Rear handle cover
( G ) Rear handle
( H ) Cushion
( J ) Rear handle heater
( K ) Handle grip
( L ) Stator assembly
(A)
(B)
(C)
(D)
(E)
(F)
(G)
(H)
(J)
(K)
(L)
