Echo shindaiwa CS-501SX

REAR HANDLE AND CONTROL SYSTEM
CS-501SX, CS-501SXH
501sx
61
9-2 Replacing throttle trigger
1. Loosen screw (A) and remove grip (B), rear
handle cover (C) and throttle lockout (D).
2. Inspect grip (B), rear handle cover (C) and throt-
tle lockout (D) for cracking or wear. If damaged,
replace it as required.
3. Push out spring pin (E) from rear handle using
Spring pin tool 897724-01361 (F).
4. Remove throttle trigger (G) together with torsion
spring (H).
A
C
B
F
G
H
D
E
D
