Section 8. Engines & Fire Protection Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
142 Version 2.0 April 2007
8.2.3 Secondary Engine Parameter Monitoring
The ACS monitors secondary engine parameters and reports system status through
the PFDs to the MFD for display. Sensors from the left engine send their information
to the left ACS, while sensors for the right engine send their information to the right
ACS. The engine sensors that send information to the ACS are:
Chip Detector
Fuel Filter Impending Bypass Switch
Oil Filter Impending Bypass Switch
Oil Temperature
Oil Pressure
Fire Detection
Figure 89. Secondary Engine Parameter-ACS Interface
