Section 8. Engines & Fire Protection Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
Version 2.0 April 2007 151
8.4.5 Engine Instrument Display (on MFD)
Figure 95. MFD Primary Engine Parameter Display
Primary engine parameters are continuously displayed on the upper portion of the
MFD. Primary engine parameters include N1 speed and ITT tapes, as well as digital
readouts of N2, Fuel Flow and Oil Pressure.
8.4.6 Engine (ENG) Synoptic
