Section 14. Primary Flight Display (PFD) Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
326 Version 2.0 April 2007

XPDR Page Line Select Key Options
Line Select Key 1 (R1),
ACTIVE
Active Transponder (XPDR) Source .....................................................XPDR 1
XPDR 2
Line Select Key 2 (R2),
CODE
Transponder Code Entry Field......................... Set using right concentric knob
Line Select` Key 3 (R3),
MODE
Transponder mode selection...................................................... GND (Ground)
SBY (Standby)
NOTE:
In both GND and SBY, the transponder will transition to altitude reporting
with weight-off-wheels, following takeoff and automatically transition back
to GND following touchdown
Line Select Key 4 (R4),
VFR
VFR Transponder Code Selection .. Pressing this line select key automatically
changes transponder CODE to 1200
Line Select Key 5 (R5)
NO FUNCTION
Concentric Knob (RIGHT)
Inner Knob...................................................................................... CODE entry
When the CODE line select field is highlighted, rotating the inner
knob changes the individual digits within the transponder code.
Outer Knob..................................................................................... CODE entry
When the CODE line select field is highlighted, rotating the
outer knob moves the cursor between digits within
the transponder code.
