Section 15. Multi Function Display (MFD) Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
380 Version 2.0 April 2007
⎯ Volume / Squelch
The keyboard upper right Vol/Sq knob functions identically to its PFD Vol/Sq
knob. Rotating the knob left or right decreases or increases pilot audio
volume. Pressing the knob activates squelch control and rotating the knob
left or right decreases or increases pilot squelch.
⎯ Speaker (SPKR)
Pressing the SPKR key toggles that crewmember’s cockpit overhead
speaker on/off. When the speaker is on, the keyboard light above the SPKR
key is illuminated.
⎯ Public Address (PA)
Pressing the PA key toggles the cabin speaker on/off. When the cabin
speaker is on, the light above the PA key is illuminated. The MFD Audio
Page does not have to be displayed.
⎯ Pilot Isolate (PILOT ISOL)
Pressing the PILOT ISOL key toggles the intercom mode between its current
mode and pilot isolate mode. If the intercom was already in pilot isolate
mode pressing this key has no effect. When the pilot isolate is active, the
light above the PILOT ISOL key is illuminated.
OPS
The Operations (OPS) synoptic page provides pilot interface with:
⎯ Aircraft Operations-Flight and Engine Times
⎯ Weight & Balance
⎯ V-Speed
⎯ System Tests
Aircraft Operations-Flight and Engine Times
When the OPS page is selected a display of a detailed breakdown of aircraft
operations information appears, including flight and block hours for the current
flight as well as the number of engine cycles. Also displayed are aircraft totals
for:
⎯ Flight Hours
⎯ Left Engine Hours
⎯ Right Engine Hours
⎯ Left Engine Starts
⎯ Right Engine Starts
⎯ Cycles
