Section 16. Autoflight Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
Version 2.0 April 2007 413
ALT to ALT CAP (pulses)
VOR to VOR (pulses)
LOC to LOC (pulses) including back course
GS to GS (pulses)
FMS to FMS (pulses)
GA PITCH associated with entering Go Around mode
Below are lists of the lateral, vertical, approach and speed mode annunciations that
may appear:
Table 40. Lateral Flight Mode Annunciations
Category Sub-Mode ACTIVE Text ARMED Text
Roll Hold
ROLL
Heading Hold
HDG
Navigation (FMS) FMS Armed
FMS
FMS Capture/Track
FMS
Navigation (VOR) VOR Armed
VOR
VOR Capture/Track
VOR
Navigation (LOC) LOC Armed
LOC
LOC Capture/Track
LOC
Go-Around (G-A)
HDG HOLD
Takeoff (FD Only)
TO ROLL
Table 41. Vertical Flight Mode Annunciations
Category Sub-Mode ACTIVE Text ARMED Text
Pitch Hold
PITCH
Altitude Altitude Capture
ALT CAP ALT
Altitude Track
ALT ALT
Altitude Change (ALT CHG) Climb/Descent
ALT CHG
Go-Around (G-A)
GA PITCH
Takeoff (FD Only)
TO PITCH
Table 42. Approach Flight Mode Annunciations
Approach
Category
Sub-Mode
ACTIVE Lateral
Text
ARMED Lateral
Text
ACTIVE
Vertical
Text
ARMED
Vertical
Lateral Text
LOC BC
LOC BC APPR LOC BC APPR
LOC ONLY Armed
LOC APPR
