Section 5. Oxygen Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
Version 2.0 April 2007 79
5.5.9 Pilot Oxygen
When the oxygen control knob is in the ON position, low pressure oxygen from the
regulator flows to the pilot oxygen mask(s). To use the system, the pilot need only
don the oxygen mask and breathe. Oxygen pressure is confirmed by a green flag on
the crew mask hose.
Figure 53. Oxygen Control Knob Activation
Figure 54. Crew Mask Hose Flow Indicator
