Introduction
24
5 Display angle adjustment
Adjust the angle of the display
The screen viewing angle can be adjusted to any of 6 stepped
positions when light from outside the vehicle makes viewing difficult.
Press .
The TILT/EJECT screen is displayed.
Touch .
The display will tilt upwards by one step (5°).
Each touch of the switch tilts the panel by
another step.
Pressing the switch when the display is tilted
to the 6th level (30°) will bring it back up to
its original position (0°).
• The display will open when pressing or touching or
even when tilted. When closed again, it will return to its tilted position.
• If the display is in an adjusted angle position when the vehicle ignition is
turned off, the display will automatically return to the original position (0°). If
the ignition switch is then turned to ACC or ON, the display will return to the
adjusted angle position.
• Be careful not to pinch your hands or other objects when adjusting the angle of
the display. This could cause an injury or damage to the display.
• When the display is in the TILT status, do not insert a disc or anything else into
the gap at the top. This may damage the unit and the disc.
• Observe the following cautions when adjusting the angle of the display.
<Automatic transmission vehicle>
When setting the tilt, make sure there is no interference generated
from your hand or other obstructions when setting when either in
Park, Reverse or Neutral. (If there is interference when in Drive, do
not set the tilt.)
<Manual transmission vehicle>
When setting the tilt, make sure there is no interference generated
from your hand or other obstructions when either in 1st, 3rd, 5th or
(Reverse) gear. (If there is interference, do not set a tilt
position.)
1
OPEN
2
TILT
OPEN
CD
DVD
