95
For reference
Please acknowledge that due changes in specifications and external appearance, the content of this manual
may not correspond with the device.
Rated output 15 W x 4 (1 kHz, 1% 4 Ω) (EIAJ)
Maximum output 50 W x 4 (test voltage 14.4 V)
Suitable load impedance 4 Ω (each channel)
Power source voltage
13.2 VDC (11 - 16 V)
Grounded
Power consumption
0.5 W x 4 output time approx. 3.7 A
Approx. 15 A max
Exterior dimensions 180 mm (W), 100 mm (H), 165 mm (D)
Weight Approx. 3.7 kg
Image pickup device 1/4 inch color CCD
CCD pixel count Approx. 270,000 pixels
Horizontal resolution 300TV (center) or above
Camera Focal distance f = 1.7 mm
F value 1:3.5
Field angle (hori-
zontal, vertical)
120°, 84°
TV format NTSC
Standard image output level 1Vp-p (75 Ω)
Minimum object illumination 2 lux (25IRE)
White balance format Automatic
Automatic sensitivity 1:1600 or above
Power source voltage DC6V +/- 0.3 V
Power consumption 170 mA (max.)
Cable length 11.5 m
Usage temperature range - 20°C to + 60°C
Storage temperature range - 30°C to + 80°C
Camera unit exterior dimen-
sions
(W x H x D)
Approx. 34 mm (W) x 27 mm (H) x 28 mm (D)
Weight Approx. 50 g (cable not included)
Common component
Back eye camera (optional)
