e. Insert the pin into the hole until the spring-loaded ball clicks into place.
6.4 Connecting and Disconnecting the Power Cord
Procedures described in this section should only be performed by qualified service
personnel.
6.4.1 Connecting the Power Cord to EFW5L
Refer to Figure 5. Connect the power cord as follows:
a. Locate the Power Cord Kit.
b. Locate female end with red locking button (1) and plug it into EFW5L power inlet (2).
You should hear an audible click when plug is secured.
c. Plug male end into a wall outlet.
d. When ready for use, power on EFW5L by pressing the on side (3) of the Power
Switch (Section 7.1).
6.4.2 Disconnecting the Power Cord from EFW5L
Refer to Figure 5. Disconnect the power cord as follows:
a. Press the off side (4) of the Power Switch to power off the unit.
b. Unplug male end from wall outlet.
Figure 4: Adjusting EFW5L
1
2
