ECOWITT HP2553CA - Page 29

29
Figure 20: Display Console Screen Layout
No
Description
No
Description
1
Outdoor temperature
14
Last lightning strikes
detected time / distance; daily
counts (optional sensor)
2
Outdoor Feels Like/Dew
point/Humidity/10Min.
Average Wind Direction/Max
Daily Gust
15
Indoor humidity
3
PM2.5 concentration display,
WH41/WH43/WH45 particle
detection sensor cycle display
(optional sensor)
16
RF signal bar for multi-
channel temperature and
humidity sensor(optional
sensor)
