ECS 865PE-A User Manual

53
2
Hardware Installation
X
2.6.8 Chassis Fan and 2nd Fan Connectors
The chassis fan connector (J22) and 2nd fan connector (J14) are
used to connect cooling fans. The cooling fans will provide ad-
equate airflow throughout the chassis to prevent overheating the
CPU and system board components. The system is capable of
monitoring and controlling the speed of these cooling fans. These
fans will automatically turn off once the system enters the Sus-
pend mode.
BIOS Setting
The “PC Health Status” submenu of the BIOS will display the
current speed of the cooling fans. Refer to chapter 3 for more
information.
Chassis fan
X
2nd fan
1
3
On/Off
Power
Sense
1
3
On/Off
Power
Sense
