Page #14 background image
Cadence II Fetal Monitor Service Manual
－ 14 －
PIN4 Earth: 0V
PIN5 VDD
PIN6 VEE
Definitions for 50Pin jack J10 pins:
PIN No. Function Description
PIN1 VO
PIN2 AA0
PIN3 WR
PIN4 RD
PIN5 LCDAD0
PIN6 LCDAD1
PIN7 LCDAD2
PIN8 LCDAD3
PIN9 LCDAD4
PIN10 LCDAD5
PIN11 LCDAD6
PIN12 LCDAD7
PIN13 LCDCS
PIN14 LCDRST
PIN15 LCDVEE
PIN16 Earth: 0V
PIN17 PD0
PIN18 PD1
PIN19 PD2
PIN20 PD3
PIN21 PD4
PIN22 PD5
PIN23 PD6
PIN24 PD7
PIN25 /ACK
PIN26 PE
PIN27 /STB
PIN28 /ERR
PIN29 BUSY
PIN30 VCC
PIN31 Earth: 0V
PIN32 VCC
PIN33 ALARM_G
PIN34 VCC
PIN35 ALARM_R
PIN36 Earth: 0V
PIN37 POWER_LED
PIN38 Earth: 0V
PIN39 VDD
PIN40 Earth: 0V
PIN41 K0
PIN42 K5
PIN43 K1
PIN44 K6
PIN45 K2
