Cadence II Fetal Monitor Service Manual
－ 15 －
PIN46 K7
PIN47 K3
PIN48 K8
PIN49 K4
PIN50 K9
Definitions for J1 JTAG
Definitions for J3 RJ-45
Definitions for J5 RS-232
PIN No. Function Description
PIN1 TCK
PIN2 Earth: 0V
PIN3 TDO
PIN4 VCC
PIN5 TMS
PIN6 NRESET
PIN7 VCC
PIN8 NULL
PIN9 TDI
PIN10 Earth: 0V
PIN No. Function Description
PIN1 T1OUT
PIN2 R1IN
PIN3 Earth
PIN4 TA
PIN5 TB
PIN6 RA
PIN7 RB
PIN8 485EN
PIN No. Function Description
PIN1 Earth
PIN2 T1OUT
PIN3 R1IN
PIN4 Earth
PIN5 Earth
PIN6 TA
PIN7 TB
PIN8 RA
PIN9 RB
