Definitions for J4 FSPO2
Definitions for J6 POWER COM
Definitions for J8 FM
Definitions for J9 DECG
Definitions for J7 CON6
PIN No. Function Description
PIN1 FSPO2RXD
PIN2 FSPO2TXD
PIN3 VCC
PIN4 Earth: 0V
PIN5 VDD
PIN6 Earth: 0V
PIN7 VEE
PIN No. Function Description
PIN1 BATTXD
PIN2 BATRXD
PIN3 Earth: 0V
PIN4 POWER_LED
PIN5 NULL
PIN6 NULL
PIN No. Function Description
PIN1 VCC
PIN2 VCC
PIN3 Earth: 0V
PIN4 VDD
PIN5 Earth: 0V
PIN6 VEE
PIN7 FHRTXD
PIN8 FHRRXD
PIN9 Earth: 0V
PIN No. Function Description
PIN1 DECGRXD
PIN2 DECGTXD
PIN3 VEE
PIN4 Earth: 0V
PIN5 VDD
PIN6 VDD
PIN7 Earth: 0V
PIN8 VCC
PIN No. Function Description
PIN1 VCC
PIN2 Earth: 0V
PIN3 CTCK
PIN4 CTDO
PIN5 CTDI
PIN6 TMS
