DCP 350
RF(PC/SC) : Contactless Smartcard Encoding
EDIsecure
®
DCP 350 printer has the internal and external contactless smartcard encoder. RF(PC/SC) is to
read and write the contactless smartcard. Using internal encoder, the printer brings a card into the printer from
input hopper and encodes a smartcard. Using external encoder, after putting a card on the top cover, you can
encode because the antenna installed under the top cover is used. Therefore, “Batch” is applied only to the
internal contactless smartcard encoding.
“Contact” is to contact with the contactless smartcard electrically and initialize.
“Reset” is to finish the function electrically. After “Contact”, you can run “Read”, “Write” and “Clear”.
“Read” and “Write” are to read and write the defined data (Name, Address and Phone). These could not be
applied to all cards.
“Clear” is to clear the displayed data (ATR, Name, Address and Phone).
In case the data is read and written using APDU, Read/Write can be done by APDU commands.
“Load APDU” is to read the stored APDU commands.
“Save APDU” is to save the displayed APDU commands.
“Clear APDU” is to clear the APDU section.
“Send APDU” is to run the APDU commands.
Batch process repeats the following steps sequentially, “IN” Move “RF” RF “Connect” RF “Write”
RF “Read” RF “Discontact” Card “OUT”
Pic.84 Contactless smartcard encoding
4.2.6 Printer status
“Get Temperature” is to get and display the temperature of Thermal Print Head. When the “Realtime Check”
is ticked, it displays the current temperature of Thermal Print Head in real time.
“Get Status” is to get and display the printer status.
