3.2.7 Electrical data: single-phase pumps
Note:
We recommend using regional supply protecon of the maximum rangs specied in
Table: Electrical data (single-phase pumps with Part Numbers ending in -903 or -906)
and Table: Electrical data (single-phase pumps with Part Numbers ending in -904).
Protecon of a higher rang must not be used.
The dual-voltage, dual-frequency motor is designed for a single-phase electrical supply
and is suitable for 50 Hz or 60 Hz operaon. The motor can be manually switched
between nominal supply voltages of 110‑120 V and 220‑240 V (refer to Check and
congure the motor on page 27). When a cold pump is started, the motor will draw the
start-up current shown in Table: Electrical data (single-phase pumps with Part Numbers
ending in -903 or -906) and Table: Electrical data (single-phase pumps with Part Numbers
ending in -904) for up to several seconds. An appropriate rated and pre-approved me-
lag fuse must be used to prevent unnecessary fuse failure during pump start-up (in
accordance with local and regional electrical codes). Within ve minutes, as the oil in the
pump warms up, the current drawn will slowly reduce to the full load current specied
in Table: Electrical data (single-phase pumps with Part Numbers ending in -903 or -906)
and Table: Electrical data (single-phase pumps with Part Numbers ending in -904).
Table 11 Electrical data (single-phase pumps with Part Numbers ending in -903 or -906)
Pump
Nominal supply (V) Frequency (Hz) Power (W) Full load current (A)
RV3, RV5, RV8 and
RV12
220-240 50 450 3.4
230-240 60 550 3.0
110 50 450 6.8
115-120 60 550 6.9
Table 12 Electrical data (single-phase pumps with Part Numbers ending in -904)
Pump
Nominal supply (V) Frequency (Hz) Power (W) Full load current (A)
RV3, RV5, RV8 and
RV12
200 50 450 4.2
200-210 60 550 4.1
100 50 450 8.3
100-105 60 550 8.0
Table 13
Recommended regional supply protecon
Area
Voltage (V) Rang
(A)
UK 230 5
Europe 230 5
USA 110 13
Japan 100 13
Electrical cables
Recommended cord sets and fuses for regional requirements.
