4.6.2 Connect the pump to the electrical supply
WARNING:
Ensure that the electrical installaon of the RV pump conforms with local and
naonal safety requirements. The pump must be connected to a suitably fused and
protected electrical supply with a suitable earth point. For recommended cord sets
refer to Electrical cables on page 22.
Note:
To prevent automac restart of the pump-motor if the electrical supply is restored aer
an electrical supply failure, connect the pump to the electrical supply through suitable
control equipment which must be reset manually aer an electrical supply failure.
1.
Ensure that the on/o switch on the motor (Figure: Motor voltage conguraon:
single-phase pumps, item 4) is in the ‘o’ posion.
2.
Insert the moulded IEC connector at the end of the cable into the electrical inlet-
connector on the motor (Figure: Motor voltage conguraon: single-phase pumps,
item 2).
3. Connect the plug (if ed) at the other end of the cable to the electrical supply. If a
plug is not ed, connect the wires in the cable to the correct terminals of the
electrical supply.
4.6.3 Check the direcon of rotaon
CAUTION:
Ensure that the pump-motor rotates in the correct direcon. If it does not, the pump
and the vacuum system can become pressurised.
Refer to Figure: The RV pump for the item numbers in brackets.
1.
Watch the motor cooling-fan through the motor fan-cover (13).
2. Use the on/o switch (12) to switch-on the electrical supply to the motor for a few
seconds.
3.
Check that the motor cooling-fan rotates in the correct direcon (14) shown by the
arrow on the motor fan-cover. If the direcon of rotaon is incorrect, switch o the
electrical supply immediately and contact us or the supplier for advice.
03/2021 - ©Edwards Limited
Page 28A65201880_AA
A65201880_AA - Installaon
