▪ If using the pump in a high ambient temperature with a high gas throughput, the
temperature of the pump-body may exceed 70 °C. We recommend the use of
addional guarding to prevent contact with hot surfaces under these condions.
▪ Make sure that the exhaust pipeline cannot become restricted. Maximum exhaust
pressure is shown in Table: General performance data. If an exhaust-isolaon valve
is ed, ensure the pump cannot be operated the pump with the valve closed.
▪ Provide for a purge of inert gas when shung down the pumping system, to dilute
dangerous gases to safe concentraons. A suitable gas ballast adaptor for
introducon of purge gas into the pump is available as an accessory (see Gas-
ballast adaptor on page 53). Contact our Applicaon team for further advice on
diluon requirements if required.
4.3 Unpack and inspect
WARNING:
The mass of the RV8 and RV12 pumps is approximately 29 kg.
For the RV8 and RV12 pumps aach the mechanical liing equipment to the liing
bracket on the pump. Slings do not need to be used to move the RV8 and RV12
pumps.
1. Remove all packing materials and remove the pump from its packing-box.
2. Remove the protecve covers from the inlet and outlet-ports and inspect the
pump. If the pump is damaged, nofy the supplier and the carrier in wring within
three days, state the Item Number of the pump together with the order number
and the supplier’s invoice number. Retain all the packing materials for inspecon.
Do not use the pump if it is damaged.
If the pump is not to be used immediately, replace the protecve covers. Store the pump
in the condions, described in Storage on page 49. Refer to Disposal on page 49 for
disposal of materials.
4.4 Locate the pump
The RV3 and RV5 pumps have a liing handle enabling the pump to be moved by hand.
If using mechanical liing equipment, do not aach the equipment to the handle; for
stability, use slings around the motor and the pump-body.
Provide a rm, level plaorm for the pump. Locate the pump so that the oil-level sight-
glass is visible and the oil ller-plug, oil drain-plug, mode selector and gas-ballast control
are accessible.
If the pump will be located inside an enclosure, to ensure the ambient temperature
around the pump does not exceed 40 °C, adequate venlaon is required at both ends
of the pump. There must be a minimum space of 25 mm between the pump and the
enclosure walls.
