STP-301/451 Series Instruction Manual
13-5
Specification
13.2 Specifications of the STP Control Unit
Table 13.2 Specifications of the STP Control Unit
Item Specifications
Input voltage VAC
100 to 120+/-10% (100V specification)
200 to 240+/-10% (200V specification)
At start: VA 550
Input power
Under rated operation: VA 150
Input frequency Hz 50/60 +/-2
Leakage current value mA 3.5
Input phase Single phase
Rated current 7.5A
Main
breaker spec
AIC: Ampere Interrupting
Capacity
1000A (AC240V, 50/60Hz)
Motor drive system 3-phase DC brush-less motor driver
Output voltage under rated operation
(3-phase)
VAC 31 to 62
Output frequency under rated
operation
Hz
420 to 800
Ambient temperature range °C 0 to 40
Storage temperature range °C -25 to +55
Mass kg 7
Dimensions mm W209.5 x H132.5 x D315
Operation switches [Front Panel]
z START switch
(momentary push button, green)
z STOP switch
(momentary push button, red)
z RESET switch
(momentary push button, white)
z SELECT switch
(momentary push button, white)
z MANUAL/REMOTE changeover switch
(slide switch, gray)
Panel indication lamps z ACCEL. lamp (green LED)
z NORMAL lamp (green LED)
z BRAKE lamp (yellow LED)
z POWER lamp (green LED)
z FAILURE lamp (red LED)
z REMOTE lamp (green LED)
Panel display z LCD panel (16 characters)
Input/output terminals z AC POWER CON1 (3 pins)
z P.CONNECTOR CON2 (45 pins)
z I/O TB1 (20 pins)
z I/O TB2 (6 pins)
z CON 4 (Optional accessory) (24 pins)
Input/output cables z Primary power cable
z STP connection cable
z Ground cable
