STP-301/451 Series Instruction Manual
3-1
Installation
3 Unpacking
3.1 Unpacking the STP Pump and the STP Control Unit
Check the following before unpacking the STP pump and STP control unit.
1) Check the package for bruises, breakage, wetness, and other.
If there is any abnormality/error or it is judged necessary to return the product, contact
Edwards or the selling agency.
2) Check the contents of the package.
See Section 3.2, "Accessories."
◇ Be careful not to scratch the flange of the STP pump.
Before installing the STP pump, check whether or not there are scratches on the
surface.
◇ It is recommended to keep the packaging materials, such as the corrugated
fiberboard container and cushioning material for possible reuse.
3.2 Accessories
Table 3.1 Accessories
Item Q'ty Remarks
STP control unit 1
Primary power cable
*1
1 With a single-side connector
STP connection cable
*1
1 With both-side connectors
Ground cable
*1
1 With both-side crimp-type terminal lugs
Inlet port cover 1
Outlet port cover 1
STP connector cover 1
Spare fuses 250V, 10A 2 F1, F2 (rear panel)
Instruction Manual 1
The accessories listed below are supplied to the chemical specific pump (type C) in addition
to the accessories in Table 3.1.
Table 3.2 Accessories for Chemical Specific Pump (Type C)
Item Q'ty Remarks
Blank flange for purge port 1 KF
*2
10
Clamping ring for purge port 1 KF
*2
10
O-ring washer for purge port 1 KF
*2
10
*1
: The standard cable length is 3 m.
*2
: JIS
