EET PMC-D726M - Page 28

CET Electric Technology
28
Figure 3-4 P.F. Convention
5) There are two ways to calculate kVA:
Mode V (Vector method):
2
2
totaltotal
kvarkWkVA
total

Mode S (Scalar method):
c
kVAkVAkVAkVA
ba
total

6) COM SET is only available for PMC-D726M with the RS485 option.
7) The AO setup parameters are only available for PMC-D726M with the AO option.
The AO Keys are shown below.
Value
Parameters
Value
Parameters
Value
Parameters
0
Ia
5
Ubc
10
kWc
1
Ib
6
Uca
11
kW Total
2
Ic
7
ULL avg
12
PF Total
3
I avg
8
kWa
13
FREQ
4
Uab
9
kWb
Table 3-7 AO Key
8) DO SET is only available for PMC-D726M with the DO option.
9) The Pulse Constant setup parameter can be configured as 1000/3200/5000/6400/12800 per kXh for a PMC-
D726M with 1A Current Input, 1000/3200/5000 per kXh with 5A and 2.5mA Current Inputs, and 40/100/400
per kXh for 40mA Current Input respectively, where kXh may be kWh or kvarh. The default values of 40 and
3200 correspond to a PMC-D726M with 40mA Current Input and other Current Inputs which include 5A, 1A
and 2.5mA, respectively.
10) For 2.5mA (SCCTA Option for 5A SCCT) Current Input, the AMP SCL would be displayed as 5A too.
