32Service Guide: EFI Fiery Central integrated server
Replacing parts
2 Replace the following cables:
• CPU power cable
• Motherboard power cable
• UIB cable
• Hard disk drive (HDD) cables
• DVD drive cables:
• Power and data combination cable
• SATA data cable
• Front panel USB port cables
• Speaker cable
• Power button cable
• Reset button cable
• Front panel fan cable and 3-pin fan extension cable
3 Secure cables as necessary with any plastic cable clamp that you may have removed earlier.
4 If you reinstalled the old motherboard, reassemble the FC integrated server and verify its functionality (see
page 53).
5 If you replaced the motherboard with a new motherboard, do the following
• Remove the battery (see page 37).
• Wait two minutes to allow the motherboard electrical components to fully discharge.
• Reinstall the battery.
• Reassemble the FC integrated server (see page 53).
• Reset the time and date in Windows Control Panel.
Important: Connect the thin, black SATA power cable connectors to the hard disk drive and DVD drive.
Do not connect the white, 4-pin power cable connectors. Connecting both types of power cables will
damage the hard disk drive and DVD drive.
Important: Make sure that unused connector panel slots are covered with slot covers. Uncovered slots reduce
air flow and may cause the FC integrated server to overheat.
