65Service Guide: EFI Fiery Central integrated server
Troubleshooting
• Each DIMM is well-seated.
• DIMM edge connectors are not oxidized.
DIMMs for FC integrated server, page 33
User interface board (UIB) is:
• Present
• Correctly attached to its bracket
• Appears undamaged
UIB cable is:
• Present
• Firmly connected in the correct connector on the motherboard and the
back of the UIB
• Not visibly damaged
User interface board, page 23
CPU is:
• Present
• Well-seated
• Not visibly damaged
The CPU cooling assembly is:
• Well-aligned
• Firmly attached
CPU with cooling assembly, page 33
Fan is:
• Properly positioned (not backwards)
• Installed in the correct connector
The fan, fan cable, cable connector, and mating connector are not visibly
damaged.
Front panel fan, page 39
The power supply required is:
• Present
• Correctly installed
• Not visibly damaged
Cable connectors are:
• Firmly connected
• Not visibly damaged
• Installed in the correct devices
Power supply, page 40
Table 1: Verifying the system (Continued)
Conditions to verify Part and additional page references
