81Service Guide: EFI Fiery Central integrated server
Servicing the Fiery Central integrated server with furniture
6 Use the allen key to loosen the screw that secures the monitor pole to the FC integrated server.
The allen key should be stored in the side drawer of the furniture.
7 Holding the monitor pole, gently lift the monitor pole assembly up and out of the FC integrated server monitor
mount.
8 Continue servicing the Fiery controller.
1Allen key
1 Monitor pole
