EG4 6500 - Input, Output, and Battery Settings

03
AC input voltage range
Appliances (default)
If selected, acceptable AC input
voltage range will be within
80-140VAC.
UPS
If selected, acceptable AC input
voltage range will be within
90-140VAC.
05
Battery type
AGM (default)
Flooded
User-Defined
If “User-Defined” is selected,
battery charge voltage and low DC
cut-off voltage can be set up in
program 26, 27 and 29.
LIb-protocol compatible
battery
3
rd
party Lithium battery
If using EG4 batteries you will
use this battery type for BMS
communications. If this
battery type is selected
settings 2,26, 27 will be
configured by the BMS.
