EG4 6500 User Manual

Table 4 General Specifications
MODEL 6.5KW
Safety Certification
UL 1741 Certificate by TUV
Operating Temperature Range -10°C to 40°C
Storage temperature -15°C~ 60°C
Humidity
5% to 95% Relative Humidity (Non-condensing)
Dimension
(D*W*H), in
58.03in x 170.2in x 226.6in (244.3in) (with extension box)
Net Weight, lbs
40.5lbs
Table 5 Parallel Specifications (Parallel model only)
Max parallel numbers
6
Circulation Current under No Load Condition
Max 2A
Power Unbalance Ratio
<5% @ 100% Load
Parallel communication
CAN
Transfer time in parallel mode
Max 50ms
Parallel Kit
YES
Note: Parallel feature will be disabled when only PV power is available
EG4 Electronics
www.eg4electronics.com
Dry Contact Relay
There is one dry contact (3A/250VAC) available on the bottom of the inverter display. It can be used to
deliver signal to external device when battery voltage reaches a set warning level.
Unit Status Condition
Dry contact port:
NC & C NO & C
Power Off Unit is off and no output is powered. Close Open
Power On
Output is
powered
from Battery
power or
Solar energy.
Program 01
set as USB
(utility first)
or SUB (solar
first)
Battery voltage < Low DC
warning voltage
Open Close
Battery voltage > Setting
value in Program 13 or
battery charging reaches
floating stage
Close Open
Program 01 is
set as SBU
(SBU priority)
Battery voltage < Setting
value in Program 12
Open Close
Battery voltage > Setting
value in Program 13 or
battery charging reaches
floating stage
Close Open
EG4 Electronics
www.eg4electronics.com
9
