2-6. Expanding Signal Output Range
●
To extend the output range
The output range of the signal is extended
to
0 - 255 for display. When images are displayed in black and white
within the restricted range for purposes such as image creation, use this setting to improve the contrast of the
images.
Settings Function
On Theoutputrangeofthesignalisextendedto0-255fordisplay.
Off Thesignaloutputrangeisnotextended.
Auto Themonitorautomaticallyrecognizesthebrightnessrangeofinputsignalsanddisplays
imagesappropriately(recommended).
Procedure
1. Choose “Screen” from the Adjustment menu, and press
.
2. Choose “Range Extension” from “Screen”, and press
.
3. Choose “Range Extension” from “Range Extension”, and press
.
4. Select “On”, “Off”, or “Auto” with
or .
Attention
• When the DVI signal is input, “Auto” cannot be selected.
5. Press to exit.
●
To select the range of signals to extend
The method for extending signals can be selected by turning the “Super white” setting “On” or “Off”.
Settings Function
On Theoutputrangeofthesignalisextendedfrom16-254to0-255fordisplay.
Off Theoutputrangeofthesignalisextendedfrom16-235to0-255fordisplay.
Procedure
1. Choose “Screen” from the Adjustment menu, and press
.
2. Choose “Range Extension” from “Screen”, and press
.
3. Choose “Super White” from “Range Extension”, and press
.
4. Select “On” or “Off” with
or .
5. Press
to exit.
Attention
• If “Range Extension” is turned “Off”, the setting can be changed but the change will not be applied.
