Elan D16 - Bus a Input Menu; Bus B Input Menu

ELAN HOME SYSTEMS D16 INSTALLATION MANUAL
© ELAN Home Systems 2010 | All rights reserved.
Page 25
Utility Sub-Menu (Continued)
Bus A Input Menu
This menu setting determines if BUS A audio signal is routed from the ANALOG audio input
for inputs 1 and 2 or is routed from OPTICAL DIGITAL audio input A.
Once you have selected the Utility sub-menu by cycling through the MAIN Menu options
using the MENU button, use the CHANNEL button to select the BUS A Input menu. Use the
UP and DOWN arrow buttons to select the desired input.
Bus B Input Menu
This menu setting determines if BUS B audio signal is routed from the ANALOG audio input
for inputs 9 and 10 or is routed from OPTICAL DIGITAL audio input B.
Once you have selected the Utility sub-menu by cycling through the MAIN Menu options
using the MENU button, use the CHANNEL button to select the BUS B Input menu. Use the
UP and DOWN arrow buttons to select the desired input.
D16 UTILITY MENU
NORM MODE
Inputs 1 & 2
BUS A:
Analog 1 & 2
D16 UTILITY MENU
NORM MODE
Inputs 9 & 10
BUS B:
Optical 2
Figure 2-19
BUS A Input Menu
Figure 2-20
BUS B Input Menu
