Utility Sub-Menu (Continued)
Firmware Version
This menu displays the current Firmware Version of the D16 chassis. Once you have
selected the Utility sub-menu by cycling through the MAIN Menu options using the MENU
button, use the CHANNEL button to select the Firmware Version screen.
Diagnostics Menu
The Diagnostics menu provides easy access to current D16 system status. Diagnostics
information displayed on the D16’s front panel include the number of times the unit has
suffered fault conditions (F) and high temperatures (T) for each channel.
A Fault (F) problem occurs when a channel is shorted or the impedance drops below 4
ohms.
A Temperature (T) warning will occur when the temperature rises above 125C.
Once you have selected the Utility sub-menu by cycling through the MAIN Menu options
using the MENU button, use the CHANNEL button to select the Diagnostics screen. Use
the UP and DOWN arrow buttons to display additional channels.
D16 UTILITY MENU
NORM MODE
D16 Firmware
Version:1.0.0.4
D2Audio Firmware
Version:1.0.0.17
D16 UTILITY MENU
NORM MODE:DIAGNOSTICS
CH:1 F:4 T:0
CH:2 F:4 T:0
CH:3 F:0 T:0
CH:4 F:0 T:0
Press Up/Dn For More
Figure 2-22
Firmware Version Screen
Figure 2-23
Diagnostics Screen
