ELAN HOME SYSTEMS D16 INSTALLATION MANUAL
© ELAN Home Systems 2010 | All rights reserved.
Page 33
ELAN Mode (Continued)
Utility Sub-Menu Additions (In ELAN MODE)
VIA!NET Address Menu
Once you have selected the Utility sub-menu by cycling through the MAIN Menu options
using the MENU button, use the CHANNEL button to select the VIA!NET Address menu.
This menu sets the VIA!NET Address for the amplifier chassis as 1 of 16 possible
addresses.
The default setting is 0.
The options are 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A, B, C, D, E, and F providing a total of 16
chassis.
The amplifier will need to be set to an I.D. that is not already being used by another
'D Series' amplifier.
D16 UTILITY MENU
ELAN MODE
VIA!NET Address:0
Figure 2-23
VIA!NET Address Menu
