ELAN HOME SYSTEMS D16 INSTALLATION MANUAL
© ELAN Home Systems 2010 | All rights reserved.
Page 60
Specifications
Audio Section
Output Power RMS
75WPC @ 4 Ohms, 50WPC @ 8 Ohms all channels driven
Frequency Response
20Hz to 20kHz - +/- 1.5 dB at 8 Ohms
Full Power Bandwidth
10Hz to 25kHz
Signal to Noise
> 102 dB (A weighted)
Channel Separation
> -70dB (channel to channel @ 1kHz)
Total Harmonic Distortion
< .04%
Inter-modulation Distortion
< 0.1%
Input Impedance
49k Ohms
Connectors
Input/Loop Output
RCA Stereo
Speaker Output
Gold Plated 5 Way Binding Post
Power
AC Power Requirements
120VAC, 1300W / 240VAC, 1300W
Current Draw
12A @ 120 VAC / 6A @ 240VAC
Standby Power saving Mode
21W
Triggers
Remote Trigger Input
5 to 24 Volts AC/DC
Loop Output Trigger
+12VDC @ 100 mA
Dimensions w/Feet (3U w/o Feet
In.
17 W x 5 7/8 H x 17 D
mm.
432 W x 149 H x 432 D
Weight
lbs.
47.6
Kg.
21.59
