ELAN HOME SYSTEMS D16 INSTALLATION MANUAL
© ELAN Home Systems 2010 | All rights reserved.
Page 50
Stand-Alone Stereo Bussing with Multiple Chassis
Prerequisites First D16 Chassis: Factory Default the amp and set to ELAN Mode.
Channel Range: Set to 1 to 16
VIA!NET Address: Set to 0
Input Select Menu: Channel All ODD with Input set to 1 Bus A
Channel All Even with Input set to 2 Bus A
Prerequisites Second D16 Chassis: Factory Default the amp and set to ELAN Mode.
Channel Range: Set to 17 to 32
VIA!NET Address: Set to 1
Input Select Menu:
Channel All ODD with Input set to 1 Bus A
Channel All Even with Input set to 2 Bus A
See:
Restore Defaults on page 29, Operating Mode Menu on page 23
Channel Range Menu on page 34, VIA!NET Address Menu on page 33
Input Select Menu on page 17
Appendix A: IR / VIA!NET Command Set
This example shows the preamp output of an A/V Receiver being distributed in a wide-area
application, such as a great room. Speakers for both chassis are stereo for up to 32 pairs
of speakers.
(Wiring example on next page.)
