ELAN Special Application - IR / VIA!NET Control
Prerequisites: Factory Default the amp and set to ELAN Mode.
Channel Range: Set to 1 to 16 / VIA!NET unit ID set to 0.
Connect IR / VIA!NET input.
See:
Restore Defaults on page 29, Operating Mode Menu on page 23
VIA!NET Address Menu on page 33, Channel Range on page 34
Link / Unlink commands in Appendix A: IR / VIA!NET Command Set
With the IR / VIA!NET input connected you can control the D16's volume output directly.
Instead of sending ELAN zone volume commands to the ELAN A/V Controller, send D16's
Channel 1 Volume Up/Down or Channel 2 Volume Up/Down IR Commands to the D16.
ELAN Special Application - IR / VIA!NET Control (additional chassis)
Prerequisites: Factory Default the D16s and set to ELAN Mode.
Channel Range: Set chassis one to 1-16 and chassis two to 17 – 32.
VIA!NET Address: Set to 0 on the first chassis and 1 on the second chassis.
Connect IR Loop / VIA!NET between the chassis.
Instead of sending ELAN zone volume commands to the ELAN A/V Controller, send D16's
Channel 17 Volume Up/Down or Channel 18 Volume Up/Down IR Commands to the D16.
Since Channel Range is set to 17 - 32, you must control the channel's volume using
different commands. When a D16 Channel Range is set to 17 - 32, the D16 is the second
chassis in a two D16 chassis system.
