33
Karl Truitt
3/03
Diagram B
Controller, User Interface Board
Reference ONLY
See Drawing
J2
Version A
Version B
Reed Switch
J2
Reed Switch
Pin 1
Pin 1
J1
J1
Section C - Diagrams
