In compact machines the rinse is active while the auto rinse lever is activated, without any delay.
*** Procedure for manually setting the “Max. motor curr.” parameter:
1. Wait until the machine, complete with tables, is ready for a wash cycle.
2. Start a wash cycle without putting racks in the machine and read the current absorbed by the gear
motor ( refer to par. A1 DISPLAY OF AUXILIARY VALUES).
3. Add 2 to the read value (e.g. if “Motor current” = 34 ---> 34+2=36 decA).
4. Set the “Max. motor curr.” parameter with the value thus obtained.
WARNING:
The Rack Type leaves the factory with the “Max motor curr.” parameter already set to the optimum
value. Reset it only when replacing a PCB or the gear motor.
Speed nr. 1
(Hz)
Capacity speed
nr. 1 (racks/hour)
Delay speed nr. 1
(sec)
Speed nr. 2
(Hz)
Capacity speed
nr. 2 (racks/hour)
Delay speed nr. 2
(sec)
WTM140 25 80 22 45 140 12
WTM165 27 90 20 51 165 11
WTM180 35 110 15 59 180 9
WTM200 40 130 13 63 200 9
WTM250 53 160 10 83 250 6
WTM300 60 180 9 100 300 5
