List of events documented by the DATALOG:
Event
number
Event name Event description Event value (VALUE)
1 BOIL. TEMP. HIGH The boiler temperature has exceeded the temperature set point
by 7 °C/13 °F.
Indicates the boiler temperature at the time
of event recording.
2 DUO TEMP. HIGH The duo rinse temperature has exceeded the temperature set
point by 8 °C/14 °F.
Indicates the duo rinse temperature at the
time of event recording.
3 WASH. TEMP. HIGH The wash tank temperature has exceeded the temperature set
point by 8 °C/14 °F.
Indicates the wash tank temperature at the
time of event recording.
4 PREW. TEMP. HIGH The prewash tank temperature has exceeded the temperature
set point by 35 °C/63 °F.
Indicates the prewash temperature at the
time of event recording.
5 DT TEMP. HIGH The dry tunnel temperature has exceeded the temperature set
point by 15 °C/27 °F.
Indicates the dry tunnel temperature at the
time of event recording.
6 BOIL. TEMP. LOW During the wash phase the boiler temperature has decreased
by more than 12 °C/25 °F with respect to the permissible min.
value (– hysteresis temperature set point).
Indicates the boiler temperature at the time
of event recording.
7 DUO TEMP. LOW During the wash phase the duo rinse temperature has decreased
by more than 15 °C/27 °F with respect to the permissible min.
value (–hysteresis temperature set point).
Indicates the duo rinse temperature at the
time of event recording.
8 WASH TEMP. LOW During the wash phase the wash tank temperature has
decreased by more than 15 °C/27 °F with respect to the
permissible min. value (–hysteresis temperature set point).
Indicates the wash tank temperature at the
time of event recording.
9 DT TEMP. LOW During the wash phase the dry tunnel temperature has
decreased by more than 15 °C/27 °F with respect to the
permissible min. value (–hysteresis temperature set point).
Indicates the dry tunnel temperature at the
time of event recording.
11 AIRG. FILL. TOUT Alarm number 11 has occurred:
The Air Gap was not completely filled within the max. filling time.
Indicates the air gap level at the time of
event recording.
12 AIRG. LEV. FAULT Alarm number 12 has occurred:
The pressure sensor on the rinse module electronic board does
not work correctly.
Indicates the air gap level at the time of
event recording.
13 DUO FILL. TOUT Alarm number 13 has occurred:
The Duo-rinse tank was not completely filled within the max.
filling time.
Indicates the duo rinse level at the time of
event recording.
14 DUO LEV. FAULT Alarm number 14 has occurred:
The pressure sensor on the Duo-rinse tank does not work
correctly.
Indicates the duo rinse level at the time of
event recording.
15 BOIL. HEAT. TOUT Alarm number 15 has occurred:
The required temperature was not reached in the boiler within the
max. heating time.
Indicates the boiler temperature at the time
of event recording.
16 BOILER OVERTEMP. Alarm number 16 has occurred:
The water temperature in the boiler is too high
Indicates the boiler temperature at the time
of event recording.
17 BOILER NTC SHORT Alarm number 17 has occurred:
The boiler temperature sensor is short circuited.
Not significant
18 BOILER NTC OPEN Alarm number 18 has occurred:
The boiler temperature sensor is open.
Not significant
19 DUO HEAT. TOUT Alarm number 19 has occurred:
The required temperature was not reached in the Duo-rinse tank
within the max. heating time.
Indicates the duo rinse temperature at the
time of event recording.
20 DUO OVERTEMP. Alarm number 20 has occurred:
The water temperature in the Duo-rinse tank is too high.
Indicates the duo rinse temperature at the
time of event recording.
21 DUO NTC SHORT Alarm number 21 has occurred:
The Duo-rinse tank temperature sensor is short circuited.
Not significant
22 DUO NTC OPEN Alarm number 22 has occurred:
The Duo-rinse tank temperature sensor is open.
Not significant
23 RIN. PUMP THERM. Alarm number 23 has occurred:
SHORT COMPACT AND MODULAR: The rinse pump thermal
protector has tripped.
Not significant
24 DUO PUMP THERM. Alarm number 24 has occurred:
The Duo-rinse pump thermal protector has tripped.
Not significant
25 DRAIN DUO TOUT Alarm number 25 has occurred:
The Duo-rinse tank was not completely emptied within the max.
emptying time.
Indicates the duo rinse level at the time of
event recording.
27 INVERTER ERROR Alarm number 27 has occurred:
The motor control inverter has generated an error.
Indicates the selected speed at the time of
event recording.
30 DRAIN AIRG TOUT Alarm number 30 has occurred:
The Air gap was not completely emptied within the max.
emptying time.
Indicates the airgap level at the time of event
recording.
31 WASH FILL. TOUT Alarm number 31 has occurred:
The wash tank was not completely filled within the max. filling
time.
Indicates the wash tank level at the time of
event recording.
32 WASH LEV. FAULT Alarm number 32 has occurred:
The pressure sensor on the wash tank does not work correctly.
Indicates the wash tank level at the time of
event recording.
33 WASH HEAT. TOUT Alarm number 33 has occurred:
The required temperature in the wash tank was not reached
within the max. heating time.
Indicates the wash tank temperature at the
time of event recording.
